12V 3.0A 36W IP68 waterproof Power Supply
Feature
◎ LED driver is designed to be enclosed in an aluminum alloy casing with rubber-sealed cables, achieving an IP68 waterproof protection rating.
◎ Crafted from pure aluminum metal, the casing protects against collision shocks and lightning strikes.
◎ The LED driver lighting transformer, with an AC 200-250V input and DC 12V output in 2 ways, can support up to 36 watts at 50/60 Hz frequency.
◎ The power supply provides safe electrical connections, converting home AC power to DC for a flicker-free lighting solution.
◎ Suitable for LED strip lights LED light bulbs outdoor advertising light boards lighting projects wall washer lamps and underground lamps.
specification
| MODEL | LED POWER SUPPLY | DM-36W 12V | DM-36W 24V |
| OUTPUT | Output voltage | 12V DC | 24V DC |
| Output voltage range | 12VDC±0.5VDC | 24VDC±0.5VDC | |
| Output Current | Max 3.0A | Max 1.5A | |
| Output power | Max 36W | ||
| Output power range | 0~36W | ||
| Ripple & Noise | ≤120mV | ≤240mV | |
| Linear Regulation | ±1% | ||
| Load Regulation | ±1% | ||
| Start-up Time (Typ) | 600ms/230VAC | ||
| Hold Up Time(Typ) | 100ms/230VAC | ||
| INPUT | Input voltage | 200-240Vac | |
| Frequency | 50/60Hz | ||
| Input сurrent | 0.52A/230Vac | ||
| Power factor | PF>0.8 | ||
| No-load power consumption | ≤3W | ||
| Efficiency (typ.) | 91% | 93% | |
| Inrush current(typ.) | Cold start 50A at 230Vac | ||
| Control surge capability | L,N:2KV L,N-PE:4KV | ||
| Leakage сurrent | Max. 0.5mA | ||
| ENVIRONMENT | Working temperature | ta: -30°C~ 50°C tc: 80°C | |
| Working humidity | 20 ~ 99%RH, condensing (Waterproof) | ||
| Storage temp., humidity | -40°C ~ 80°C, 10~95%RH | ||
| PROTECTION | Overtemperature | Protection type: Turn off the output voltage, after the temperature drops, re-energize to restore. | |
| Over load protection | Shut down the output when current load above 110%~150%, auto recovers. | ||
| Short circuit protection | Protection type: It can be automatically restored after the fault is eliminated. | ||
| SAFETY&EMC | Withstand voltage | I/P-O/P:3750Vac | |
| Isolation resistance | I/P-O/P: 100MΩ/500VDC/25°C/70%RH | ||
| Safety standards | IEC/EN61347;IEC/EN60950;IP67 | ||
| EMC Test Standards | EN55015: 2013;EN61547: 2009; EN61000-3-2:2014; EN61000-3-3:2013 | ||
| Reliabilityand Quality Control | Impact aging | 100% of the product is fully loaded and impacted for 4 hours under an environment of at least 40°C±5°C | |
| Component derating | Under the steady-state conditions of rated input and output, the stress of components will not exceed its maximum nominal value | ||
| NOTE | 1.All parameters not specifically mentioned are measured at 230VAC input, rated load and 25°C ambient temperature. 2.Ripple and noise test method: connect 0.1uF and 47uF capacitors in parallel at the terminal, and measure under 20MHZ bandwidth. 3.Ensure that the power supply is used under the rated parameters and environment. | ||
OEM Customer design
010203
Model List
Below DM series are 100% full load, and 5 years warranty! Our factory offers OEM customization, allowing us to tailor various models and parameters to meet your specific needs. Feel free to contact us for more information and personalized solutions.
| Model | Power Out | Input Voltage | Output Voltage | Output Current | Efficiency | IP | Size(mm) | Package |
| DM-36W 12V /24V | 36W | 200-240V AC | 12V/24V | 5.0A/ 1.5A | 93% | IP68 | 126*41*27 | 60 |
| DM-60W 12V /24V | 60W | 200-240V AC | 12V/24V | 5.0A/ 2.5A | 93% | IP68 | 143*49*31 | 40 |
| DM-100W 12V /24V | 100W | 200-240V AC | 12V/24V | 8.3A/ 4.1A | 93% | IP68 | 164*53*31 | 30 |
| DM-150W 12V /24V | 150W | 200-240V AC | 12V/24V | 12.5A/ 6.25A | 93% | IP68 | 176*57*34 | 20 |
| DM-200W 12V /24V | 200W | 200-240V AC | 12V/24V | 16.7A/ 8.33A | 92% | IP68 | 186*60*36 | 20 |
| DM-300W 12V /24V | 300W | 200-240V AC | 12V/24V | 25.0A/ 12.5A | 92% | IP68 | 200*67*36 | 16 |
| DM-400W 12V /24V | 400W | 200-240V AC | 12V/24V | 33.3A/ 16.7A | 92% | IP68 | 230*67*36 | 16 |
application
The 12V 3A 36W IP68 waterproof power supply is designed for harsh and moisture-prone environments, providing stable, reliable power for LED lighting in wet, dusty, and corrosive conditions. With its IP68-rated full waterproof and dustproof design, it is ideal for both indoor and outdoor applications where exposure to water, humidity, or extreme weather is a concern.
● Bathroom & Smart Mirror Lighting – Perfect for LED bathroom mirrors, vanity mirrors, and smart mirrors, ensuring safe and stable power even in high-humidity conditions.
● Outdoor & Garden Lighting – Suitable for landscape lighting, pathway lights, garden LED strips, and fountain lighting, withstanding rain, humidity, and soil contact.
● Coastal & High-Salinity Areas – Designed for seaside lighting, docks, and marine applications, resisting salt corrosion and extreme weather conditions.
● Dusty & Industrial Environments – Ideal for factories, warehouses, and workshops, where high dust levels and rough conditions require a fully sealed power supply.
● Underground & Waterproof Installations – Used in subway stations, underground tunnels, and drainage systems, where water exposure is frequent.
● Outdoor Advertising & Architectural Lighting – Powers LED signage, facade lighting, and decorative outdoor installations, providing long-lasting, reliable illumination in extreme weather.
With its IP68-rated full protection, durable waterproof housing, and high efficiency, this power supply ensures safe and stable operation in demanding environments, making it an excellent choice for both residential and industrial applications.
